Anycubic Photon P1 Max Review: Big Resin Prints That Actually Work

Why Large Resin Printers Usually Disappoint

Most large-format MSLA printers force a choice. You can print big, or you can print sharp. Anycubic says the Photon P1 Max does both. After testing the machine, the claim holds up better than expected, though a few quirks remain.

Specs and Build Volume

The P1 Max offers a 285.5 x 214 x 300 mm build volume, which works out to 18.3 liters. That is enough for a full-size helmet, a batch of miniatures, or a bulky prototype in one go. The 12K 14-inch screen sounds like a downgrade next to the 14K standard P1, but the 4:3 aspect ratio keeps pixel size at 24.8 microns, so detail stays on par with smaller machines.

The vat holds 1,900 ml and includes integrated heating up to 40C. That helps high-viscosity resins flow better in cooler rooms. Anycubic rates noise under 45 dB, which is unusually quiet for a printer this size.

Wave Release and AI Detection

The headline feature is Wave Release Technology. The printer monitors interlayer separation force in real time and adjusts lift height and speed accordingly. Anycubic says this lets the machine handle resins up to 8,000 cP, which is well above the standard 1,000 to 3,000 cP range most home resin printers manage.

Intelligent Printing Assistant 3.0 adds four AI checks: build platform installation, first-layer separation, resin level, and cured-residue detection. In practice, these catch the most common failure modes before they waste a full vat of resin. The system is not perfect, and false positives can happen, but it is a useful safety net.

Real-World Printing

Setup is straightforward. The printer weighs 23.1 kg, so you will want help moving it. Once in place, the folding lid opens high enough for easy access, and the touchscreen interface follows the same layout as other Photon models. WiFi file transfer and a 1080p camera are included.

Print quality is strong for props, helmets, and terrain. The heated vat and Wave Release system make a noticeable difference with tough resins. The main trade-off is speed: large prints are still slow, and the printer's size means you need roughly 85 cm of height clearance to fully open the dome.

Pricing and Competition

The Photon P1 Max lists at $999 with an early-bird price of $849. That puts it between the Phrozen Revo Max and the ELEGOO Jupiter 2. The Jupiter 2 has a sharper 16K screen but no high-viscosity optimization. The Revo Max has dual heating but lacks the AI detection suite. For resin users who print big and use engineering materials, the P1 Max is the most balanced option of the three.
